Cimon Plc Software
Powerful and compact, CIMON PLCs deliver unsurpassed performance and functionality at competitive prices. Our CIMON PLCs are available in modular, brick or mixed designs with the option of 4 different CPU models, making them a perfect fit for any size application. The modular design allows you to add components as needed to your CPU, such as Digital or Analog I/O, High Speed Counters, Positioning Modules, Communication modules, and many more. The brick style modules are already equipped with these features; they have Digital I/O as well as High Speed Counters integrated into the unit. The high-end CM1-XP CPU module offers a modular PLC with the capability of adding up to 8,192 I/O points in addition to a complete Redundancy System, making for a fail-safe system. The CM1-CP CPU module is another modular-type PLC with a scan time of 200ns/Step, offering all of the same modules and capabilities as the CM1-XP module minus the Redundancy System. The CM1-CP and CM1-XP CPUs offer modules that are unique to their PLC line, such as Data Loggers, Load Cell, BACNET and Profibus modules.
Trojan er html jscript cf. Your site still has that history of ' HAD MALWARE ' back in 2012.6.
The CM3-SP CPU offers the best of both worlds; designed with both brick and modular features. The CM3-SP CPUs are equipped with Digital I/O, two 20Kpps High-Speed Counters, two 100Kpps pulse outputs, and 32 PID channels with auto-tuning.
The CM3-SP CPU product line also offers additional modular components as well, such as Digital and Analog I/O, Thermal Sensing, Ethernet and Serial Modules. Lastly the CM3-SB CPU series is a brick-type PLC with all the same integrated features as the CM3-SP series minus the positioning I/O. However the CM3-SB series is a more ideal fit for smaller applications that do not need more than 16 I/O points.
Cimon Scada
CIMON PLCs are perfect for any range of application; contact an Anaheim Automation Applications Engineer for assistance in selecting the appropriate model for your application.CPU ModulesCIMON PLCs are offered in four different designs, delivering a versatile solution for both large and small applications. Three different options are available; modular, mixed units and brick-type.
The larger style PLCs allow for expansion, offer several types of communication options, and provide you with just the right features necessary for your application without additional cost! The modular CM1 PLCs offer the most variety when it comes to expansion modules, offering; a redundancy system, analog and digital I/O, high speed counters, positioning, communication, temperature, data logger, and power modules are all offered in this unit.
Designed for small to medium applications is the mixed CM3-SP unit which comes fully integrated with pulse train outputs for stepper control, high speed counter inputs for encoder feedback, and PID auto-tuning. These CM3-SP units allow for up to 384 I/O points, including AD, DA, temperature, and communication modules. The brick-style CM3-SB units are an economical solution for smaller application that have integrated high-speed counters and digital I/O. Redundancy SystemThe CIMON Redundancy product line is meant to make your system completely fail-safe! The CIMON Redundancy system can protect you from power failure, communication failure as well as protection from CPU errors. System Redundancy is useful for applications that require zero down time, operate 24/7 or can put people's lives at risk if the system fails, such as; water dams, chemical manufacturers and airport traffic control.
Cimon Plc Software Download
The Redundancy system requires you that you have two bases a primary and secondary, which include; a power supply, power monitoring module, redundancy CPU, redundancy interface, redundancy communication module and a base to house all modules. Digital I/O ModulesCIMON's Digital I/O Modules are offered in multiple different configurations; modules are available with only inputs, only outputs or both inputs and outputs.
Their modularity and expandability make them ideal for even the largest applications. The units are available in either Sinking or Sourcing with either Transistor or Relay-type outputs. The PLC-CPU-XP is capable of handling up to 8,192 I/O points, the PLC-CPU-CP up to 1,024 points, the PLC-CPU-SP up to 384 I/O points, and the PLC-CPU-BP up to 128 I/O points. All modules are photo-coupler insulated so that units are not damaged. Analog ModulesCIMON's Analog I/O Modules are offered in 4, 8, or 16 digital channels, allowing for extreme flexibility in a number of different applications.
The XP and CP CPU series can also use the digital to analog modules that output from -10VDC to 10VDC. The analog to digital modules are available in either a 14-bit or 16-bit resolution, and can output -10VDC to 10VDC or 0VDC to 10VDC. These modules are ideal for use with Anaheim Automation's Brushless Drivers, which can take up to a 5VDC signal for speed control.
Communication ModulesThe CIMON line of Communication Modules allows the user to incorporate additional units into a system without having to worry about numerous communication protocols. The communication line offers RS232C, RS422/285, Ethernet, BACnet, Profibus, CDMA and CANopen which allows for the integration of a SCADA system to alert users of all facets of the production line. The RS232C and RS422/485 units are utilized for communication with production line controllers/drives via MODBUS or any other ASCII based protocol. Ethernet provides high speed up to 100Mbps so the user can forward real-time data to a Supervisory Software. The Profibus communication module enables seamless communication between different manufacturers' devices. The BACnet module can be used in various applications such as HVAC control systems, lighting control systems, security systems and many more. Temperature Sensing ModulesCIMON's RDT Module converts inputted temperature data by using a platinum-coated thermometer Pt100, JPt100 or Pt1000, NI1000.
Capable of processing inputted temperature data down to the first decimal place, capable of detecting a wire disconnection from each channel, and detecting excess range of input temperature, this line of RDT Modules greatly simplifies processes for the user. One module can connect with Pt100, JPt100 or Pt1000, Ni1000 with 4 point and 8 point to use respectively. Data Logger ModulesThe CIMON Data Logger Module is a larger capacity unit providing real-time data sampling and saving.
Equipped with non-combustible log memory (32MB), the modules data can be acquired at any time from a SCADA system. This unit is great for storing production line data, such as; daily items produced, daily down time, and amount of injuries. This module offers a self-diagnostic function that can detect communication and memory errors as well perform capacity checks.
The data logger can be written to periodically, it can be triggered or it can be event based. Power ModulesCIMON power supplies provide the necessary output for all CM1 modules. This sleek, modular unit is designed specifically for the system's current consumption—so no need to overpay for an over engineered power supply! There are 4 different models, all promising 70% or more efficiency; each unique to a system design. AC and DC modules are offered in 4 different output voltages that can handle up to 3.5 Amps. These power supplies save the user both time and money; they are easy to install and are selected specifically based on system design, making them ideal for applications requiring both high performance and cost-efficiency.
